A Metal Siding Roll Forming Machine is a highly efficient and versatile tool used to produce metal siding panels for residential, commercial, and industrial applications. These machines are critical for manufacturers looking to create durable, aesthetically pleasing, and weather-resistant siding solutions. Metal siding is widely used in the USA due to its strength, longevity, and ability to withstand diverse climates.
Machine Description
A Metal Siding Roll Forming Machine is designed to transform flat metal coils into profiled siding panels with precise dimensions and consistent quality. These machines are built to handle various materials, including galvanized steel, aluminum, copper, and zinc, depending on the application.
Key features of the machine include:
- High Precision Rollers: Engineered to produce consistent profiles with minimal material waste.
- PLC Control System: Ensures automated operation with high accuracy.
- Hydraulic Cutting System: Guarantees clean and precise cuts without burrs.
- Customizable Profiles: Supports a wide range of siding designs, including lap siding, vertical panels, and batten profiles.
- Durable Construction: Heavy-duty frame and components designed for high-volume production.
Specifications
| Feature | Details |
|---|---|
| Material Compatibility | Galvanized steel, aluminum, copper, zinc |
| Material Thickness | 0.4 mm to 0.8 mm |
| Coil Width | 1000 mm to 1250 mm |
| Production Speed | 10-30 meters per minute |
| Roller Material | High-grade steel with hard chrome plating |
| Number of Rollers | 12–18 rollers (depending on the profile) |
| Cutting System | Hydraulic or servo-controlled cutting system |
| Power Requirements | 380V/3-phase/60Hz (customizable for the USA) |
| Control System | PLC system with touch-screen interface (brands like Siemens or Mitsubishi) |
| Machine Dimensions | 7000 mm x 1500 mm x 1200 mm |
| Weight | Approx. 6 tons |
Advantages
- Efficiency: High-speed production for large-scale projects.
- Versatility: Customizable profiles to meet various architectural styles.
- Durability: Sturdy construction ensures long-lasting performance.
- Ease of Operation: User-friendly PLC systems for smooth operation and minimal downtime.
- Low Waste: Accurate forming reduces material wastage, enhancing cost-effectiveness.
Applications in the USA
- Residential Projects: Metal siding for homes offering weather resistance and low maintenance.
- Commercial Buildings: Durable and customizable siding solutions for offices and stores.
- Industrial Facilities: Protective and long-lasting panels for factories and warehouses.
Extras and Options
- Stackers: For automated stacking of finished panels.
- Uncoilers and Recoilers: Ensures smooth feeding and winding of metal coils.
- Remote PLC System: Allows for remote operation and monitoring.
- Pre-Punching Systems: Adds holes or slots before forming.
- Customized Profiles: Tailored to meet unique project requirements.
Question and Answer Section
1. What is the cost of a Metal Siding Roll Forming Machine in the USA?
The cost ranges from $50,000 to $120,000, depending on the machine's specifications, production speed, and additional features.
2. What types of materials can this machine handle?
The machine is compatible with materials like galvanized steel, aluminum, copper, and zinc, with thicknesses ranging from 0.4 mm to 0.8 mm.
3. Can the machine be customized for specific profiles?
Yes, the machine can be customized to produce various metal siding profiles, including lap siding, vertical panels, and batten designs.
4. What are the power requirements for the machine?
The standard power requirement is 380V/3-phase/60Hz, but it can be customized for USA-specific standards.
5. How long does installation take?
Installation typically takes 5–7 days, including setup and testing by professional technicians.
6. Is training provided with the purchase?
Yes, most manufacturers include operator training and a detailed user manual with the machine.
7. What is the maintenance schedule for this machine?
Regular maintenance includes:
- Cleaning rollers after each production run.
- Lubricating moving parts monthly.
- Inspecting the hydraulic system quarterly.
8. Can this machine produce insulated panels?
No, this machine is designed for metal siding panels. For insulated panels, a specialized machine is required.
Metal Siding Roll Forming Machine in the USA
- Condition
- New
- Listing ID
- 8769
- Supplier
- Roll Forming Machines United States
- Location
- United States
