The Composite Decking 2-Inch Roll Forming Machine is a state-of-the-art industrial machine designed to produce 2-inch composite decking panels for commercial and residential projects. These decking panels are widely used in flooring systems due to their strength, durability, and lightweight nature, making them ideal for various applications such as multi-story buildings, parking decks, and mezzanines. The machine automates the production process, ensuring consistent quality, high efficiency, and cost-effective manufacturing.

Key Features

Automated Production: Equipped with advanced PLC systems for precise control over the entire process.
High-Speed Performance: Produces decking profiles at a rate of up to 40 meters per minute.
Durable Construction: Engineered with robust materials to handle heavy-duty operations.
Customizable Profiles: Supports various panel widths, depths, and gauges to meet specific requirements.
Safety Compliance: Comes with integrated safety guards and emergency stop systems.

Specifications

Feature	Specification
Material Compatibility	Steel, Galvanized Steel, Aluminum, and Stainless Steel
Material Thickness	0.8 mm to 1.5 mm
Profile Height	2 inches (50.8 mm)
Profile Width	Adjustable, typically 12 to 36 inches (305 to 914 mm)
Roller Materials	High-grade Chrome-Plated Steel
Forming Stations	18–22 stations, depending on profile complexity
Frame Construction	Welded steel frame with vibration-resistant structure
Cutting System	Hydraulic cutting with precision tolerance
Motor Power	15 kW to 30 kW (depending on speed and capacity)
Control System	PLC with HMI interface for easy operation
Machine Speed	Up to 40 meters per minute
Power Supply	220V/380V, 3-Phase, 50Hz/60Hz
Optional Add-Ons	Automatic stackers, coil car tippers, uncoilers, and recoilers

Applications

Residential and commercial flooring systems.
Parking decks in urban areas.
Mezzanine flooring in warehouses and factories.
Roofing support systems for industrial buildings.

Setup and Installation

Delivered with a comprehensive installation guide and on-site support.
Requires a leveled and reinforced factory floor.
Minimal setup time due to modular construction and pre-assembled components.

Maintenance

Regular lubrication of rollers and moving parts.
Periodic inspection of hydraulic systems and cutting blades.
Cleaning and rust prevention for long-lasting performance.

Question and Answer Section

Q1: What is the maximum material gauge this machine can handle?
A: The machine can handle material gauges ranging from 0.8 mm to 1.5 mm.

Q2: Can the machine produce custom profile widths?
A: Yes, the machine is equipped to adjust to various profile widths, typically from 12 to 36 inches.

Q3: Is the machine suitable for Florida's industrial standards?
A: Absolutely. The machine is built to meet U.S. industrial safety and quality standards, including those specific to Florida’s construction requirements.

Q4: What is the delivery time for this machine in Florida?
A: Delivery typically takes 6-8 weeks, depending on the manufacturer and customization requirements.

Q5: How can I ensure consistent quality for high-volume production?
A: The advanced PLC control system ensures precise production settings, reducing errors and maintaining consistency.

Q6: Is technical support available locally in Florida?
A: Yes, technical support is available through local distributors or remote assistance from the manufacturer.

Q7: Can I use this machine for other decking profiles?
A: Yes, the machine can be adjusted or retooled to accommodate different decking profiles, depending on your requirements.

Composite Decking 2-Inch Roll Forming Machine Florida

Condition: New
Listing ID: 6220
Supplier: Roll forming machines LLC
Location: United States
