3″ N-Deck Roof Deck Roll Forming Machine – Canada | Machine Matcher

High-Performance Structural Roof Deck Machine for the Canadian Steel Industry

The 3″ N-Deck Roof Deck Roll Forming Machine is an advanced production line engineered to produce high-strength structural roof decking panels used in commercial, industrial, and infrastructure projects throughout Canada. Designed for precision, durability, and heavy-duty performance, this machine forms deep ribbed 3-inch N-Deck panels that deliver exceptional span capacity, composite action, and concrete bonding.

At Machine Matcher, every roll forming machine is built new to your specific profile and project requirements, ensuring full compliance with Canadian steel standards, voltage, and material supply conditions. Whether you manufacture decking panels in Toronto, Montreal, Calgary, Vancouver, or Edmonton, this equipment offers reliable, continuous production with minimal maintenance and 24/7 global technical support.

Machine Technical Specifications

Understanding the 3″ N-Deck Profile

The 3″ N-Deck profile is one of North America’s most trusted structural roof decking systems. It is characterized by deep 3-inch ribs, wide flute spacing, and continuous interlocking joints, making it ideal for long spans and composite construction.

Key Technical Advantages

• Deep ribs for superior load-bearing strength

• High efficiency in composite steel-concrete floors

• Enhanced fire and sound performance

• Quick installation with minimal field cutting

• Ideal for multi-storey and industrial buildings

Typical Uses

• Roof decking for commercial and industrial buildings

• Composite floor decking in steel structures

• Parking garages and high-rise office towers

• Bridge decks and public infrastructure projects

View related profiles and design variations in our Machine Matcher Profile Catalog.

How the N-Deck Roll Forming Process Works

1. Coil Loading:
   The steel coil is placed on the hydraulic uncoiler and securely clamped.

2. Feeding & Guiding:
   Coil passes through the entry guide and leveling system for straightness.

3. Roll Forming:
   Each roller station gradually shapes the material into the N-Deck profile with precision.

4. Cutting & Discharge:
   The PLC-controlled hydraulic shear cuts the panels to length automatically.

5. Stacking & Packaging (Optional):
   An automatic stacker arranges finished panels for easy handling.

This seamless process allows continuous production with high accuracy and low waste, ideal for large-volume operations in Canadian construction.

Industries & Applications in Canada

The 3″ N-Deck Roll Forming Machine serves the construction and infrastructure sectors, where structural decking is a critical element of design.

Industries Using N-Deck Panels

• Commercial & Industrial Construction

• Prefabricated Steel Buildings

• Infrastructure (Bridges, Stations)

• Institutional Buildings (Universities, Hospitals)

• Warehousing & Logistics Facilities

• Renewable Energy Structures (Solar Roof Systems)

Common Applications

• Roof and floor deck systems

• Formwork for reinforced concrete

• Architectural and acoustical decking

• Platforms, mezzanines, and walkways

Canadian Regions Served:

• Ontario – Toronto, Hamilton, Mississauga

• Alberta – Calgary, Edmonton

• British Columbia – Vancouver, Surrey

• Quebec – Montreal, Laval

• Manitoba, Saskatchewan, and Atlantic Provinces

Machine Matcher supports nationwide delivery and setup, including training and after-sales service.

Machine Construction & Components Explained

Roller System

Precision-machined rollers made from GCr15 bearing steel ensure long-term durability and consistent shaping. Each roller is ground, heat-treated, and hard chrome-plated to prevent wear and corrosion from high-tensile materials.

Cutting System

The hydraulic post-cut unit uses Cr12MoV tool steel blades to deliver smooth, burr-free cuts. The shear operates automatically under PLC command, synchronized with line speed.

Drive & Transmission

Choose between chain drive (cost-effective, low maintenance) or gearbox drive (higher precision and torque for thicker gauges). Drive motors are energy-efficient with overload protection.

PLC Control System

Equipped with a Siemens, Mitsubishi, or Delta PLC, operators can control panel length, batch quantity, and cutting intervals from a user-friendly touchscreen.

Safety & Maintenance

Safety guards, emergency stops, and overload systems are standard. The machine includes a lubrication system and automatic oiling options to minimize downtime.

Optional Add-Ons and Upgrades

Enhance performance and automation with optional systems such as:

• Automatic Stacker System

• Servo Feeder with Encoder

• Hydraulic Punching or Notching Station

• Coil Car or Decoiler Tipper

• Remote PLC Access via Ewon Cosy+

• Sound-Insulated Safety Enclosures

• Leveling and Lubrication Systems

• Quick-Change Roll Setup for Multiple Profiles

How to Choose the Right N-Deck Roll Forming Machine

When selecting your machine, consider:

• Profile Standard – Verify local decking profile dimensions and tolerances.

• Material Gauge & Type – Heavier gauges require higher motor power.

• Power Supply – Canada uses 575V/60Hz 3-phase systems.

• Production Capacity – Decide between 12 m/min standard or 20 m/min high-speed lines.

• Budget & Add-Ons – Automation can save labor costs long-term.

Our engineers at Machine Matcher will design your machine around your exact profile drawing and power configuration, ensuring compliance and compatibility.

Machine Pricing and Ordering Information

Pricing for the 3″ N-Deck Roll Forming Machine depends on:

• Machine length, forming stations, and speed

• Coil handling and cutting system

• PLC brand and automation level

• Optional punching or stacking units

• Electrical configuration (Canadian 575V)

For a tailored quote, please contact:

United Kingdom (Main Office)
Phone: +44 20 335 56554

United States
Phone: +1 407 559 7948

Mobile / WhatsApp: +44 7816 972935

Email: [email protected]

Maintenance and Support

Proper maintenance ensures long service life and consistent production. Machine Matcher provides full Preventive Maintenance Plans, including daily, weekly, and quarterly checklists.

Daily Checks

• Inspect coil entry guides and clean rollers

• Ensure lubrication at all key points

• Verify hydraulic pressure and oil level

Weekly Tasks

• Check chain or gearbox tension

• Inspect sensor alignment and encoder accuracy

Quarterly Tasks

• Calibrate length encoder

• Replace hydraulic oil and filters

• Check electrical cabinet for dust and heat buildup

Our 24/7 Technical Support Desk offers global remote PLC diagnostics, troubleshooting, and guidance.

Frequently Asked Questions (FAQs)

What is a 3″ N-Deck Roll Forming Machine?

It’s a cold-forming production line that shapes steel coils into 3-inch-deep structural roof decking panels used in buildings and bridges.

How to maintain a roof deck roll forming machine?

Regular lubrication, chain tension checks, blade sharpening, and hydraulic oil changes keep your machine in peak condition.

Why choose Machine Matcher?

Because we supply only new, custom-built machines, backed by 1-year warranty, 24/7 support, and global delivery.

Can the machine be customized for my profile?

✅ Yes. Send your decking profile drawing or sample, and we’ll manufacture tooling specifically for your design.

What materials can be processed?

Galvanized steel, Galvalume, and cold-rolled steel with tensile strengths up to 550 MPa, suitable for Canadian construction codes.

What is the average machine lifespan?

With proper maintenance, your N-Deck roll former can operate 15–20 years with minimal downtime.

How to order a machine?

Contact Machine Matcher with your profile details, coil gauge, and voltage, and receive a full quote, drawings, and production schedule.

Why Choose Machine Matcher

• 100% new machines, built to order

• Custom tooling for your local profiles

• Global supply network – UK, USA, Canada, UAE, and Asia

• Remote PLC & camera diagnostics available

• Pre-shipment testing with photos/videos

• Worldwide installation and operator training

• Dedicated technical team in UK and North America

Machine Matcher doesn’t just sell equipment — we build long-term partnerships to ensure every client achieves production success.

How to Order Your 3″ N-Deck Roof Deck Roll Forming Machine

1. Send your profile drawing or physical sample panel.

2. Confirm material specifications (thickness, yield strength).

3. Provide power supply details (e.g., 575V/60Hz).

4. Receive a custom machine quotation and layout drawing.

5. Machine manufactured, tested, and approved with video demonstration.

6. Worldwide delivery, installation, and on-site operator training.

Global Supply & Support

Machine Matcher supplies and supports roll forming machines in over 170 countries, including:

• Canada, USA, UK, Australia, Germany, UAE, India, and South Africa.
  We offer local engineering support, spare parts, and remote diagnostics — ensuring uninterrupted production anywhere in the world.

Final Summary

The 3″ N-Deck Roof Deck Roll Forming Machine from Machine Matcher is a precision-engineered production line designed for high-volume structural decking manufacturing. Built for Canadian voltage, materials, and industrial standards, it offers superior reliability, automation, and performance for roof and floor deck fabrication.

Every Machine Matcher roll forming machine is built new, tested before shipment, and supported 24/7 by our worldwide service team. We deliver globally, ensuring smooth installation, reliable operation, and ongoing partnership.
