The 3" N Deck Cold Roll Forming Machine is a high-performance equipment designed for the efficient production of N deck panels, commonly used in construction for roof and floor decking systems. Known for their enhanced structural integrity and versatility, 3" N decks are widely used in commercial, industrial, and residential building projects. This machine is tailored to meet the demands of manufacturers and contractors in Florida, catering to the region's booming construction industry.
Machine Description
The 3" N Deck Cold Roll Forming Machine is engineered to produce precise and durable N deck panels with a depth of 3 inches. The machine operates with advanced automation and high-speed production capabilities, ensuring consistency and quality in every panel produced. Its robust construction and intelligent control systems make it ideal for long-term industrial use.
- Durable Frame: Heavy-duty steel construction for stability and longevity.
- Advanced Rollers: High-grade alloy steel rollers with a chrome-plated finish for precision forming and extended durability.
- PLC System: An intuitive programmable logic controller (PLC) for easy operation and customization.
- Cutting System: Hydraulic cutting mechanism for clean and precise cuts.
Specifications
| Feature | Specification |
|---|---|
| Material Thickness | 0.8 mm – 1.5 mm |
| Material Width | 914 mm – 1220 mm |
| Material Type | Galvanized steel, stainless steel, aluminum |
| Roller Material | GCr15 with chrome coating |
| Number of Stations | 20–24 stations |
| Machine Speed | 10–25 meters per minute |
| Power Supply | 220V/380V, 50Hz/60Hz |
| Main Motor Power | 15 kW – 22 kW |
| Hydraulic Cutting Power | 5.5 kW – 7.5 kW |
| Control System | PLC with touch screen (brands like Siemens or Delta) |
| Dimensions | 12 m × 1.5 m × 1.5 m |
| Weight | Approximately 10 tons |
| Optional Extras | Automatic stackers, remote control systems, and coil handling equipment |
Applications
- Roofing and Flooring: Provides structural support for buildings.
- Commercial Construction: Used in warehouses, shopping centers, and parking garages.
- Industrial Projects: Ideal for factories and large-scale facilities.
Advantages
- High Efficiency: Capable of producing panels at a fast rate.
- Precision Engineering: Ensures uniform panel quality with tight tolerances.
- Durable Build: Withstands rigorous use over long production cycles.
- Automation Options: Reduces manual intervention and increases safety.
Frequently Asked Questions (FAQs)
1. What is the maximum material thickness the machine can handle?
The machine is designed to work with material thicknesses ranging from 0.8 mm to 1.5 mm.
2. What types of materials can this machine process?
It can process galvanized steel, stainless steel, and aluminum.
3. Is this machine compatible with Florida's power supply standards?
Yes, the machine is available in 220V/380V with options for 50Hz or 60Hz to suit Florida's power supply.
4. What optional extras can I add to the machine?
Optional extras include automatic stackers, remote PLC systems, and advanced coil handling equipment.
5. How easy is it to operate the machine?
The machine features a user-friendly PLC system with a touch screen for intuitive operation.
6. Can the machine be customized to meet specific requirements?
Yes, the machine can be customized for material width, thickness, and additional automation features.
7. How do I maintain the machine?
Regular lubrication of moving parts, inspection of the rollers and cutting blades, and keeping the machine clean from debris will ensure optimal performance.
8. What is the average lead time for delivery in Florida?
Delivery times vary, but typically, it ranges between 6 to 12 weeks depending on customization and shipping arrangements.
9. Does the machine come with a warranty?
Yes, most manufacturers provide a 12–18 month warranty on major components.
10. Is installation and training available?
Yes, on-site installation and operator training can be arranged in Florida.
3" N Deck Cold Roll Forming Machine Florida
- Condition
- New
- Listing ID
- 6446
- Supplier
- Roll forming machines LLC
- Location
- United States
